HTR EP01/EP01A Diamond Edge Polisher Machine

The only compact and economical table top edge polisher that is easy to operate. It removes saw marks and produces a clear polished edge on acrylic sheets in single pass through the machine.

Features:

• Compact, economical and easy to operate.
• Multiple workpieces can be fed using 2 constant gear-driven belts.
• Special diamond cutter & 24000 RPM precision spindle.
• Variable feed rate (0-10 ft/minspeed controls)
• Depth indicator and base for setting cutter height provided.

Specification:

• Table Size : 33 x 56 cms
• Track Length : 117 cms
• Max. Thickness : 20 mm
• Weight of the Machine : 43 kgs.
• Dimensions (LxWxH) : 56 cms x 33 cms x 45 cms
